产品参数

光源:

光束端:

10 x 60W RGBW LED

频闪端:

96 x 3W CW LED

96 x 3W WW LED

96 x 0.5W RGB LED

白光色温: 6,300K

光通量: 22,400 lm

LED预期寿命: 20,000小时

光学系统

缩放角度:

光束角度: 2.8°-31° (光束端)

光斑角度: 5°-46° (光束端)

控制与程序

5个按键

控制面板: LCD显示屏

控制协议: DMX512, RDM

DMX 通道模式: 7种

通道模式: 17/27/99/108/168/8+100/8+160/170 通道

软件升级: 通过 DMX 连接更新软件

Y轴

Y轴运作角度: 202°

电气与接口

输入电源: 180-240V~ 50/60Hz

功率: 800 W

电源插座: 电源连接器输入/输出

信号输入/输出: 三芯或五芯卡侬头插座, RJ45

产品尺寸：100＊29＊12/cm

单品包装：108＊36＊18/cm

产品净重：18.1kg

包装标准：电源线一条、信号线一条、说明书一份，吊挂件一套

Light source:

Beam end:

10 x 60W RGBW LED

Strobe terminal:

96 x 3W CW LED

96 x 3W WW LED

96 x 0.5W RGB LED

White light color temperature: 6,300K

Light lux: 22,400 lm

LED life expectancy: 20,000 hours

Optical system

Zoom angle:

Beam angle: 2.8°-31° (beam end)

Spot angle: 5°-46° (beam end)

Control and procedures

5 keys

Control panel: LCD display

Control protocol: DMX512, RDM

DMX channel mode: 7 types

Channel mode: 17/27/99/108/168/8+100/8+160/170 channel

Software upgrade: update the software through DMX connection

Y-axis

Y-axis operation angle: 202°

Electrical and interface

Input power supply: 180-240V~ 50/60Hz

Power: 800 W

Power outlet: power connector input/output

Signal input/output: three-core or five-core cannon head socket, RJ45
